Auto-door Magnetic Lock
There are 5 Similar products,Comparison
Magnetic Lock for Auto-door
Model:YAD-160ML
YAD-160ML is exlusively used for the automatic door with 70kg(150lbs) linear holding force, which works under magnetic mechanism. It is adopted with special design for access control systems. This device can be installed on the Dorma automatic system as well.
Keywords:
Share to:
Product Parameter Parameter Description
Lock Size  L70xW70xH58(mm)
Armature plate  100Lx53Wx53H(mm)
Holding Force  70kg(150Lbs)
Voltage  DC12V±10%
Current Draw  DC12V/180mA
Suitable for  Auto-door
Surface Temp  About 50°
Operating Temp -10~55℃(14-131F)
Suitable Humidity 0~90%(relative humidity)
Surface Treatment High Temperature Paint and Environmental Protection Zin
Weight 0.8kg
Certification CE-EMC
Special design and suitable for any auto-door.
No Fault Diagnosis,safety ,durable.
Professional design,easy to install.
Selected product by Auto-door manufacturer.
CE Certificate by European Union.

 coming soon


Warranty Service will be honored if the damage is not caused by human, YLI Provides 1 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service centre.

YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.

Packing Quantity(PCS/CTN) 20
Packing Size(L*W*H)(cm) 60*35*16.5
Gross Weight(KG) 14.4

YDG-1、YDG-2
